08:00 - 08:05
nanoGe Introduction
08:05 - 08:15
Opening Chair 1A
Session 1A
Chair: Ho Won Jang
08:15 - 08:35
1A-I1
Lee, Jang-Sik
Postech
Emerging Memory Devices with Metal-Halide Perovskite Materials
Lee, Jang-Sik
Postech, KR
Authors
Jang-Sik Lee a
Affiliations
a, POSTECH
Abstract

Emerging nonvolatile memory technologies such as phase change memory, spin-transfer torque-magnetic memory, and resistive switching memory (ReRAM) have been investigated as next-generation technology to replace conventional flash memory. Among them, ReRAM has been extensively studied for nonvolatile memory applications owing to its excellent retention, endurance, and high on/off ratio. Furthermore, ReRAM has a simple two-terminal structure, fast switching speed, and low power consumption with excellent scalability. ReRAM cells can be integrated into a cross-point array to obtain an area-efficient structure. In addition to planar cross-point arrays, 3D stackable cross-point arrays have been recently considered to maximize the ReRAM density. Among various materials for use in ReRAM inorganic metal oxides have been investigated widely. Recently, active research has been done on the fabrication and characterization of ReRAM devices utilizing emerging materials. Especially, hybrid organic-inorganic perovskite materials have been used as the resistive switching layer in ReRAM devices. In this presentation, a strategy toward design of high-density memory devices utilizing metal-halide perovskite materials will be discussed in detail with an emphasis on practical applicability, scalability, and reliability.

08:35 - 08:55
1A-I2
Wu, Tom
UNSW Sydney
Hybrid Perovskites: An Emerging Class of Highly Tunable Light-Responsive Semiconductors
Wu, Tom
UNSW Sydney, AU
Authors
Tom Wu a
Affiliations
a, UNSW Sydney, Samuels Building, Kensington, AU
Abstract

As an emerging class of light-responsive semiconductors, hybrid organo-metal perovskites seamlessly marry the characteristics of organic and inorganic materials. Perovskites have been on the radar screen of material scientists for over a century, before the reign of silicon, but only a decade ago they started receiving a strong wave of renewed interests thanks to their extraordinary photovoltaic performance. The hybrid nature of organo-metal perovskites leads to a unique combination of highly tunable physical properties such as superior visible light absorption, decent charge transport, defect tolerance, solution processing, and even ferroelectric-like polarization. In this talk, I will share our view on the opportunities and challenges of hybrid perovskites and their heterostructures, with a focus on the potential electronic applications. I will discuss an effective strategy towards enhancing the device performance of hybrid perovskites via coupling with low-dimensional materials. We found that combining 3D hybrid perovskites with 1D carbon nanotubes or 2D two-dimensional metal dichalcogenides significantly enhances charge transport and device performance. I will also discuss perovskite-based opto-ion-electronics, with photo-memories as an example, which leverages on highly correlated electrons, ions, and photons in halide perovskites.

08:55 - 09:15
1A-I3
Han, Su-Ting
Shenzhen University
Functional Memristor for In-Sensor Computing
Han, Su-Ting
Shenzhen University, CN
Authors
Su-Ting Han a
Affiliations
a, Shenzhen University, Room 909, Zhiteng Building, Naihai Avenue 3688, Shenzhen, CN
Abstract

The development of internet of things and artificial intelligence induces the rapid growing of sensory nodes which generates a large portion of unstructured and redundant raw data. In the conventional design, the analogue sensory data are initially transformed into digital data with analogue-to-digital conversion, then stored in memory unit. The computational task is further performed by transferring the digital data between memory and local computation unit. The architecture of separated sensor, memory and data processing units results in the data-accessing latency and relatively high-power consumption. Alternatively, near-sensor computing with accelerator or processing unit reside besides sensor to execute computational task and in-sensor computing with individual sensors or multiple connected sensor to directly process information have been proposed to improve energy, area and time efficiency [1, 2].

However, transistor-based chips and single devices to implement near-/in-sensor computing make them bulky, energy-inefficient and complicated. The devices with relatively compact structure and simple operation mode are highly required. Memristor is a two-terminal electronic device featured by nanometer size, storage capacity and dynamic continuous variable resistance. In a typical bipolar resistive switching device, the switching of high resistance state (HRS) and low resistance state (LRS) is driven by the application of voltage above the set voltage. The rich dynamic properties of ion migration and electronic-ionic coupling ensures that memristor is the promising candidate for near-/in-sensor computing. In additon, the multi-field controlled memristor is expected to further scale down the chip size. In this presentation, we will discuss the benefit of functional memristor technologies in the application of near-/in-sensor computing [3-6].

References

[1] Kagawa, K. et al. IEEE J. Sel. Top. Quantum Electron. 2004, 10, 816

[2] Mennel, L. et al. Nature 2020, 579, 62

[3] S.-T. Han* et al. Matter 2021, 4, 1702

[4] S.-T. Han* et al. Nature Commun. 2021, DOI 10.1038/s41467-021-26314-8.

[5] S.-T. Han* et al. Adv. Funct. Mater. 2021, 31, 2100144

[6] S.-T. Han* et al. Adv. Mater. 2018, 30, 1802883

09:15 - 09:30
Discussion
09:30 - 09:45
Break
Session 1B
Chair: Ho Won Jang
09:45 - 10:05
1B-O1
Bisquert, Juan
Instituto de Tecnología Química (ITQ-UPV-CSIC)
Impedance spectroscopy characterization of memristors and neurons in relation to spiking and hysteresis effects
Bisquert, Juan
Instituto de Tecnología Química (ITQ-UPV-CSIC)

Juan Bisquert (pHD Universitat de València, 1991) is a Professor of applied physics at Universitat Jaume I de Castelló, Spain. He is the director of the Institute of Advanced Materials at UJI. He authored 360 peer reviewed papers, and a series of books including . Physics of Solar Cells: Perovskites, Organics, and Photovoltaics Fundamentals (CRC Press).  His h-index 95, and is currently a Senior Editor of the Journal of Physical Chemistry Letters. He conducts experimental and theoretical research on materials and devices for production and storage of clean energies. His main topics of interest are materials and processes in perovskite solar cells and solar fuel production. He has developed the application of measurement techniques and physical modeling of nanostructured energy devices, that relate the device operation with the elementary steps that take place at the nanoscale dimension: charge transfer, carrier transport, chemical reaction, etc., especially in the field of impedance spectroscopy, as well as general device models. He has been distinguished in the 2014-2019 list of ISI Highly Cited Researchers.



Authors
Juan Bisquert a
Affiliations
a, Institute of Advanced Materials (INAM), Universitat Jaume I, 12006 Castelló, Spain
Abstract

A memristor is a device that has different metastable states at a voltage V. It has a resistance that depends on the history of the system, and the states can be switched by applied voltage. A memristor is a device with very large hysteresis. Neurons have the same ingredients as memristors plus at least one negative resistance. The neuron can undergo a Hopf bifurcation that passes the dynamics from rest to a spiking state. We provide impedance spectroscopy criteria to identify these features. First, we show the impedance model of a halide perovskite memristor, that exhibits inductive behaviour due to inverted hysteresis. We introduce the concept of a chemical inductor and explain the general kinetic model that generates such behaviour in a variety of systems. Next, we show the full dynamical regimes of a FitzHugh-Nagumo model, that is a representative minimal model of a spinning neuron

10:05 - 10:25
1B-O2
Gogoi, Himangshu Jyoti
Indian Institute of Technology Guwahati
Measurement Process - Dependent Performance and Conduction Mechanism of Hybrid Perovskite Memristors
Gogoi, Himangshu Jyoti
Indian Institute of Technology Guwahati
Authors
Himangshu Jyoti Gogoi a, Arun Tej Mallajosyula a
Affiliations
a, Indian Institute of Technology Guwahati
Abstract

Hybrid organic-inorganic perovskite (HOIP) memristors are being studied extensively in recent times as a potential alternative to conventional memory technologies as well as to mimic the function of biological synapse in neuromorphic circuits [1]. In this work, the conduction mechanism and performance of MAPbI3-based memristors have been studied. These devices exhibited an excellent ON/OFF ratio of greater than 103. However, it has been found that measurement procedure brings significant variations in their performance [2]. While the RESET voltage and current significantly increase with scan rate, the ON/OFF ratio increases significantly with compliance current. Also, the forming voltage and ON/OFF ratio decrease with device scaling. In the case of voltage pulse characterization, the ON/OFF ratio can be enhanced by increasing the pulse amplitude and width. Hence, the selection of proper pulse amplitude and width is of utmost importance in achieving high endurance with desired noise margin. Based on these results, a protocol has been identified for the characterization of HOIP memristors to achieve their best possible switching parameters. This protocol is quite general in nature and can be employed for any other memristor structure based on HOIPs as well as on other related materials. Furthermore, the experimental data fitting to a standard SPICE based analytical model indicates that the current conduction is dominated by a tunnelling mechanism in the OFF state and is ohmic in the ON state [3].

10:25 - 10:40
Discussion
10:40 - 11:00
Break
11:00 - 12:00
ePoster Session & Happy hour

Tue Dec 14 2021
08:00 - 08:05
nanoGe Introduction
08:05 - 08:15
Opening Chair 2A
Session 2A
Chair: Himangshu Jyoti Gogoi
08:15 - 08:35
2A-I1
Sirringhaus, Henning
University of Cambridge
CHARGE TRANSPORT PHYSICS OF HYBRID PEROVSKITE FIELD EFFECT TRANSISTORS
Sirringhaus, Henning
University of Cambridge, GB
Authors
Henning Sirringhaus a
Affiliations
a, Cavendish Laboratory, Department of Physics, University of Cambridge, JJ Thomson Avenue, Cambridge, GB
Abstract

Field-effect transistors based on hybrid metal halide perovskite semiconductors provide a controlled means of studying the charge transport physics of these materials and are also of interest for a broad range of applications in electronics, optoelectronics or bioelectronics. In this talk we will provide a general overview of the current understanding of the main factors that govern and limit the charge transport properties of these materials and provide specific examples of recent approaches that aim to enhance FET performance and stability. We will discuss in particular approaches to understand the effects of ion migration on the transport of electronic charges and approaches to minimze effects of ion migration.





08:35 - 08:55
2A-I2
NOH, YONG-YOUNG
Postech
Development of high performance halide perovskite transistors
NOH, YONG-YOUNG
Postech, KR

Yong-Young Noh is Chair Professor in the Department of Chemical Engineering, Pohang University of Science and Technology (POSTECH), Pohang, Republic of Korea. He received his PhD in 2005 from GIST, Republic of Korea, and then worked at the Cavendish Laboratory in Cambridge, UK, as a postdoctoral associate. Afterwards, he worked at ETRI as a senior researcher, Hanbat National University as assistant professor, Dongguk University-Seoul as associate professor. He has won Merck Young Scientist Award (2013), Korea President Award (2014), IEEE George E. Smith Award (2014), and as selected this month Scientist from Korea Government (September. 2016). He has published over 360 papers in international journals in the field of materials for electronics and optoelectric devices, in particular, OFETs, OLEDs, Metal Halide, perovskites, carbon nanotube 2D layered materials and oxide TFTs.



Authors
YONG-YOUNG NOH a
Affiliations
a, POSTECH
Abstract

Perovskites have been intensively investigated for their use in solar cells and light-emitting diodes. However, research on their applications in thin-film transistors (TFTs) has drawn less attention despite their high intrinsic charge carrier mobility. In this study, we report the universal approaches for high-performance and reliable p-channel lead-free phenethylammonium tin iodide TFTs. These include self-passivation for grain boundary by excess phenethylammonium iodide, grain crystallisation control by adduct, and iodide vacancy passivation through oxygen treatment. We found that the grain boundary passivation can increase TFT reproducibility and reliability, and the grain size enlargement can hike the TFT performance; thus, enabling the first perovskite-based complementary inverter demonstration with n-channel indium gallium zinc oxide (IGZO) TFTs. In addition, we applied the same transistors for photosensors to detect green light. Details of performance will be discussed in my presentation. The inverter exhibits a high gain over 30 with an excellent noise margin. This work aims to provide widely applicable and repeatable methods to make the gate more open for intensive efforts towards high-performance printed perovskite TFTs.

08:55 - 09:15
2A-I3
John, Rohit Abraham
Halide Perovskite Memristors for Neuromorphic Computing and Hardware Security
John, Rohit Abraham
Authors
Rohit Abraham John a, b, c
Affiliations
a, NTU Singapore - Nanyang Technological University, School of Materials Science and Engineering, Nanyang Avenue, 50, Singapore, SG
b, Department of Chemistry and Applied Bioscience, ETH Zürich, CH-8093 Switzerland, Vladimir-Prelog-Weg, 1, Zürich, CH
c, Laboratory for Thin Films and Photovoltaics, Empa − Swiss Federal Laboratories for Materials Science and Technology, Ueberlandstrasse, 129, Dübendorf, CH
Abstract

In this talk, I will cover our investigations on halide perovskite memristors for computing and hardware security. The first part of the talk will focus on designing diffusive and drift halide perovskite memristive barristors as nociceptive and synaptic emulators for neuromorphic computing [1]. Here, we will discuss the role of interfaces that play pivotal roles in determining the switching characteristics of perovskite memristors, demonstrations of nociceptors and synapses using halide perovskite memristors and their integration with robotics for in-sensory computing. In the second part of the talk, we will discuss the use case of perovskite memristors for Physical Unclonable Functions (PUFs)- a security primitive exploiting the switching physics of one-dimensional halide perovskites as excellent sources of entropy for secure key generation and device authentication [2].

09:15 - 09:30
Discussion
09:30 - 09:45
Break
Session 2B
Chair: Himangshu Jyoti Gogoi
09:45 - 10:05
2B-O1
Guerrero, Antonio
Universitat Jaume I, Institute of Advanced Materials (INAM) - Spain
Understanding low frequency capacitive effects in perovskite memristor dynamics
Guerrero, Antonio
Universitat Jaume I, Institute of Advanced Materials (INAM) - Spain, ES

Antonio Guerrero is Associate Professor in Applied Physics at the Institute of Advanced Materials (Spain). His background includes synthesis of organic and inorganic materials (PhD in Chemistry). He worked 4 years at Cambridge Dispaly Technology  fabricating materiales for organic light emitting diodes and joined University Jaume I in 2010 to lead the fabrication laboratory of electronic devices. His expertise includes chemical and electrical characterization of several types of electronic devices. In the last years he has focused in solar cells, memristors, electrochemical cells and batteries.

Authors
Antonio Guerrero a
Affiliations
a, Institute of Advanced Materials (INAM), Universitat Jaume I, 12006 Castelló, Spain
Abstract

Understanding the capacitive response in hybrid perovskite devices has been the focus of much research in recent years as it is connected with hysteresis and degradation of solar cells. Negative capacitance and loops have been observed during the analysis of Impedance Spectroscopy results. 1,2-4 The origin of these features seems to be related to the dynamic interaction of migrating ions with external interfaces and play a role in memristor switching between high and low resistance states. Here we present the dynamic state transition in a 2D Ruddlesden-Popper perovskite-based memristor device, measured via impedance spectroscopy. The spectral evolution of the transition exhibits a significant transformation of the low frequency arc to a negative capacitance arc. The capacitance-frequency evolution of the device indicates that the appearance of the negative capacitance is intimately related to a slow kinetic phenomenon due to ionic migration and further interaction with the external contacts. We discuss the internal mechanism on the basis of the device configuration and the electrical response. The switching mechanisms of devices containing a perovskite/metal contact are due to the interface chemical transformation and devices containing an organic buffer layer follow a filamentary formation.

10:05 - 10:25
2B-O2
Hill, Nathan
Physics Department, School of Electrical and Electronic Engineering, Newcastle University, United Kingdom
2-Dimensional Layered Single Crystal Perovskites and Films for Memristor and Photoresistor Applications
Hill, Nathan
Physics Department, School of Electrical and Electronic Engineering, Newcastle University, United Kingdom, GB
Authors
Nathan Hill a, Noel Healy a, Marina Freitag b, Pablo Docampo c
Affiliations
a, School of Mathematics, Statistics and Physics, Newcastle University, Herschel Building, NE1 7RU, Newcastle upon Tyne, UK.
b, School of Natural and Environmental Sciences, Newcastle University, UK, Newcastle upon Tyne, Reino Unido, Newcastle upon Tyne, GB
c, School of Chemistry, University of Glasgow, University Pl, G12 8QQ, Glasgow, UK
Abstract

2D layered perovskites have recently emerged as energy materials due to their improved stability against atmospheric degradation and low-cost solution processing methods.1,2 These materials have been investigated optically and computationally to determine their electron structure and carrier mobility,3 as well as in tandem with traditional 3D perovskites (MAPbI3) for improved interface passivation increasing solar harvesting efficiencies.4 However, up until now, little focus has been on these materials for use as memory storage devices and within IoT.

Herein we report the fabrication of a 2D layered perovskite (PEA)2PbI4 in-situ device, where large single crystals are grown vertically between device contacts using a peripheral evaporation technique.5 This achieves an easy route for encapsulation and improved stability. We show through a series of voltage scans that the devices have two resistance states that are stably switched between over 1000 voltage cycles with the HRS being five times higher than the LRS. Furthermore, we show that these devices are photoresponsive with the ON/OFF ratio decreasing due to increasing light intensity from darkness to 1 Sun intensity, which is restored once returned into the dark. We have also shown that carrier transport varies with the measurement orientation of the device when measured either vertically or laterally. Lateral devices are fabricated via spin-coating in which allows control of the crystallite size via the addition of Tetrahydrothiophene 1-oxide (THTO) thus changing the number of grain boundaries. By performing electrical characterisation during light- and temperature-dependant measurements we observe a photoresistive response in these lateral devices, for the first time allowing the characterisation of ionic transport behaviour in this material.

10:25 - 10:40
Discussion
10:40 - 10:55
Break
Session 2C
Chair: Himangshu Jyoti Gogoi
10:55 - 11:15
2C-I1
Mathews, Nripan
Nanyang Technological University (NTU)
Ionic, opto-electronic properties of halide perovskites for neuromorphic applications
Mathews, Nripan
Nanyang Technological University (NTU), SG
Authors
Nripan Mathews a, b
Affiliations
a, Energy Research Institute @ NTU (ERI@N), Nanyang Technological University, SG
b, NTU Singapore - Nanyang Technological University, School of Materials Science and Engineering, Nanyang Avenue, 50, Singapore, SG
Abstract

Halide perovskites, a family of printable materials with coupled ionic-optoelectronic properties provide a multitude of mechanisms for controlling memristive behaviour. Perovskites are well known for solar cells and light emission, but its ionic activity is unexploited. Due to both ionic and electronic transport within them, a myriad of mechanisms can be exploited to form diffusive and drift perovskite memristors - reversible doping, interfacial reactions, conductive filament formation as well as carrier trapping-detrapping. These mechanisms can be modulated by choice of perovskites, interfacial layers and morphologies. Our group’s efforts in investigation of new materials, their characterisation and deployment in two terminal and three terminal architectures will be covered.

11:15 - 11:35
2C-I2
Park, Cheolmin
Yonsei University
Nanostructured Perovskites for Retina-inspired Structurally Tunable Synapse
Park, Cheolmin
Yonsei University, KR
Authors
Kyuho Lee a, Hyowon Han a, Cheolmin Park a
Affiliations
a, Department of Materials Science and Engineering, Yonsei University, Seoul, KR, KR
Abstract

Ordered nanostructured crystals of thin perovskites films are of great interest to researchers because of the dimensional-dependence of their photoelectronic properties for developing the perovskites with novel properties [1]. In this presentation, both top-down and bottom-up approaches for fabricating nanostructured perovskite films are demonstrated. First, a variety of micro/nanopatterns of a perovskite film are fabricated by either micro/nano-imprinting or transfer-printing a thin spin-coated precursor film in soft-gel state with a topographically pre-patterned polymer mold, followed by thermal treatment for complete conversion of the precursor film to a perovskite one [2]. Second, we also demonstrate a simple and robust route, involving the controlled crystallization of the perovskites templated with a self-assembled block copolymer (BCP), for fabricating nanopatterned perovskite films with various shapes and nanodomain sizes [3]. The nanopatterned perovskites showed significantly enhanced photoluminescence with high resistance to both humidity and heat due to geometrically confining crystals in the BCP domains. We also demonstrate an artificially intelligent photonic synapse based on a floating-gated field effect transistor with area-density-tunable perovskite nano-cone arrays templated in a BCP [4]. Our device is capable of electric charge (de)trapping and photo-excited charge generation, and it exhibits versatile synaptic functions of the nervous system, including paired-pulse facilitation and long-term potentiation, with excellent reliability. The area-density variable perovskite floating gate developed by off-centered spin coating process allows for emulating the human retina with a position-dependent spatial distribution of cones.

11:35 - 11:50
Discussion
11:50 - 12:00
Closing

Posters
Seung Ju Kim, Ho Won Jang
Vertically aligned two-dimensional halide perovskites for reliably operable artificial synapses
Cedric Gonzales, Antonio Guerrero, Juan Bisquert
Impedance Spectral Evolution of the Dynamic State Transition in Perovskite-based Memristors
Aušra Selskienė, Gabrielė Kavaliauskaitė, Rokas Gegevičius, Edvinas Orentas, Vidmantas Gulbinas, Marius Franckevičius
Partial substitution of methylammonium iodide with S-methylthiouronium iodide improves photostability in hybrid perovskite solar cells
daeun lee, howon jang
RRAM with High Endurance Using All-inorganic Perovskite Quantum Dot
Yoon Jung Lee
High Hole Mobility Inorganic Halide Perovskite Field-Effect Transistors with Enhanced Phase Stability and Interfacial Defect Tolerance
Vidmantas Jašinskas, Rokas Gegevičius, Marius Franckevičius, Vidmantas Gulbinas
Variations of Carrier Dynamics in MAPI Perovskite Films Induced by Ion Redistribution
Héctor Cruanyes, Agustín Bou, Juan Bisquert
Equivalent Circuits Similarities of the Hodgkin-Huxley Model and Perovskite Memristors
Mariana Berruet, José Carlos Pérez-Martínez, Antonio Guerrero, Juan Bisquert
Interfacial reactivity and resistive switching phenomenon in MAPI-based memristors
In Hyuk Im, Ho Won Jang
Threshold switching and resistive switching of Ag cluster in organolead halide perovskite for one selector - one resistor cross-bar array

Time Converter
