Strain Engineering of Nano-porous Cu for Electrochemical CO(2) Reduction
Yuxiang Zhou a, Ayman A El-Zoka a b, Benjamin Bowers a, Rose P Oates a, Ifan E L Stephens a, Mary P Ryan a
a Department of Materials, Imperial College London, Exhibition Road, SW7 2AZ London, United Kingdom
b Max-Planck-Institut für Eisenforschung, Max-Planck-Straße 1, Düsseldorf 40237, Germany
Materials for Sustainable Development Conference (MATSUS)
Proceedings of MATSUS Fall 2023 Conference (MATSUSFall23)
#CO2X - Frontier developments in Electrochemical CO2 reduction and the utilization
Torremolinos, Spain, 2023 October 16th - 20th
Organizers: Alexander Bagger and Yu Katayama
Oral, Yuxiang Zhou, presentation 222
DOI: https://doi.org/10.29363/nanoge.matsus.2023.222
Publication date: 18th July 2023

CO2 reduction provides a carbon neutral means of converting waste CO2 and surplus electricity into valuable fuels and chemicals to reach the net zero global goal. Only Cu can yield valuable high energy C2+ products, due to its unique binding energy with *CO and *H intermediate [1], but only at the Faradaic Efficiencies of up to 52% for ethanol [2] and 87% for ethylene [3], and under high over-potentials and harsh conditions. Single crystal studies have shown that Cu(100) with surface defects (under-coordinated atoms) favours such C2+ products even oxygenated products, because of both the correct binding and low barriers for protonation and C-C coupling. Therefore, we hypothesise that by synthesizing nano-porous Cu with (100) orientation, its catalytic activity will be maximised [4 – 6].



Nano-porous materials have many potential applications as sensors, actuators, catalysis, etc, because of their large surface-to-volume ratio and high surface distortion. These structures can be produced by (electro)chemically dealloying a bimetallic alloy, in a regime where one of the components is much more chemically active than the other. As the active species are removed, the remaining material forms a nano-porous ‘sponge’ that has a bi-continuous structure, of which the amount of under-coordinated atoms is significant [7 – 8]. Inspired by the work from Chattot et al [9], where a linear relationship between the surface distortion of Pt and its oxygen reduction reactivity was found, we hypothesise that the CO2 reduction reactivity of Cu surface could also be tailored by introducing surface distortion via dealloying.



Herein, we systematically studied the corrosion behaviour of Cu20Zn80 brass, using cryo-atomic probe tomography (cryo-APT) and in situ synchrotron X-ray diffraction (XRD), as shown by Figure 1. We successfully synthesised a series of nano-porous Cu materials with different ligament sizes, ranging from tens of nanometres to micrometres, via chemical dealloying by just changing temperatures. Synchrotron XRD measurement indicates that there is a huge but different micro-strain on these dealloyed nano-porous Cu, which is caused by the under-coordinated atoms. Electrochemical CO2 and CO reduction measurement was then conducted, showing their significantly different catalytic activities, which correlated well with their micro-strains measured.



We acknowledge the European Synchrotron Radiation Facility (ESRF) for provision of synchrotron radiation facilities and we would like to thank Dr Oleg Konovalov for assistance and support in using beamline ID10.
