Investigation of Ni Doping Effect on Layered Perovskite Air Electrode for Highly Efficient Reversible Protonic Ceramic Cells
Jiwon Yun a b, Sihyuk Choi a b
a Department of Mechanical Engineering, Kumoh National Institute of Technology, Gyeongbuk, 39177 Republic of Korea
b Department of Aeronautics, Mechanical and Electronic Convergence Engineering, Kumoh National Institute of Technology, Gyeongbuk, 39177 Republic of Korea
Proceedings of 24th International Conference on Solid State Ionics (SSI24)
Emerging Materials for High-Performance Devices
London, United Kingdom, 2024 July 14th - 19th
Organizers: John Kilner and Stephen Skinner
Poster, Jiwon Yun, 576
Publication date: 10th April 2024

Hydrogen energy has attracted great interest as a renewable and sustainable energy source to achieve carbon neutrality in response to environmental pollution issues and climate change caused by the accelerated greenhouse gas emissions following industrialization. Among the several hydrogen energy systems, reversible-solid oxide cells (R-SOCs) have been regarded as promising electrochemical devices due to their excellent conversion efficiency in both power and fuel generating modes. However, the high-operating temperature of 800-1000 oC leads to serious obstacles such as incompatibility between cell components, gas-sealing, and rapid performance degradation from severe thermal stress. Reversible-protonic ceramic cells (R-PCCs) with proton-conducting oxide (PCO) electrolytes are suggested as a solution for lowering the operating temperature (400-600 oC), as proton transport requires significantly less activation energy (0.4-0.6 eV) than that of oxygen ions. Meanwhile, the electrochemical performances of R-PCCs have currently lagged behind predictions based on their high ionic conductivity due to the sluggish electrocatalytic activities of the air electrode. Thus, further development of highly efficient air electrodes for the fast oxygen reduction reaction (ORR) and the oxygen evolution reaction (OER) imperatively remains. Herein, we report a novel air electrode material, Ni-doped layered perovskite PrBa0.5Sr0.5Co2-xNixO5+d (PBSCN, x=0, 0.1, and 0.2), for R-PCCs. With increasing Ni content, the lower oxidation states of Ni and Co were significantly improved the quantitative oxygen vacancy concentration and proton concentration. The PBSCN20 air electrode exhibited outstanding electrochemical performances, exceeding a peak power density of 0.64 W cm-2 in fuel cell mode and a current density of 0.41 A cm-2 in electrolysis mode at 1.3 V and 500 oC. Furthermore, a long-term stability demonstrated excellent durability without obvious performance degradation for 700 h under fuel cell mode, electrolysis mode, and reversible operation mode.

This research was supported by National Research Foundation of Korea (NRF) (NRF- 2021M3I3A1084292).
