The underexplored tunneled-V4O9: a competitive cathode material efficiently synthesized
Ester García-González a, Chandrasekar M Subramaniyan b, Alois Kuhn b, Olga Guerrero-Pérez c, Enrique Rodríguez-Castellón d, Flaviano García-Alvarado b
a Departamento de Química Inorgánica, Facultad de Ciencias Químicas, Universidad Complutense de Madrid, Madrid 28040, Spain
b Department of Chemistry and Biochemistry, Facultad de Farmacia, Universidad San Pablo-CEU, CEU Universities, Boadilla del Monte, 28668 Madrid, Spain
c Departamento de Ingeniería Química, Facultad de Ciencias, Universidad de Málaga, 29071 Málaga, Spain
d Departamento de Química Inorgánica, Facultad de Ciencias, Universidad de Málaga, 29071 Málaga, Spain
Proceedings of 24th International Conference on Solid State Ionics (SSI24)
Fundamentals: Experiment and simulation
London, United Kingdom, 2024 July 14th - 19th
Organizers: John Kilner and Stephen Skinner
Oral, Ester García-González, presentation 263
Publication date: 10th April 2024

The rich redox chemistry of vanadium oxides has meant that they have been and continue to be the subject of exhaustive study in many areas and particularly in energy materials. High energy densities reported for vanadium oxides are related to the electrochemical activity associated with multiple V(V) to V(III) redox state changes. The large variety of stable and metastable structures are a challenge to synthesize vanadium oxides with high purity and controlled stoichiometry.

V4O9 is an intermediate crystal phase along the line from V2O5 to VO2. It is halfway in composition, although not structurally since it is not directly related to them; it is not a “shear structure” but a 3D tunnelled structure instead. Defined as a metastable phase, it has been little investigated. The use of reducing agents either in solvothermal conditions or in solid-solid or solid-gas reactions requires an accurate control of reaction conditions and usually leads to mixed phases.

In this sense and taking advantage of the exceptional catalytic properties of vanadium oxides, we have successfully prepared flake-shaped nanoparticles of V4O9 from nanoparticulate V2O5 and acetonitrile as solvent/reducer by a direct novel solvothermal method, which has proven to be very efficient and versatile. The as-prepared sample consisted of 5–20 nm average size V4O9 nanoparticles exhibiting an average oxidation state of 4.65 vanadium ions as deduced from XPS. The enhanced electronic conductivity of V4O9 is reflected in its electrochemical performances. Against Li anode upon discharge to 1.5 V, the V4O9 could intercalate ~6 Li+ corresponding to 464.8 mA h g-1 at 10 mA g-1 and exhibited reversible Coulombic efficiency of 75.2% upon charging to 4.0 V [1]. The V4O9 displayed superior rate capability at various current densities for 110 cycles and excellent long cycle stability delivering a reversible capacity of 160.8 mA h g-1 at 100 mA g-1 even after 2000 cycles. Preliminary electrochemical results against Na anode showed that V4O9 could intercalate 4 Na+ with highest first discharge capacity of 318.9 mA h g−1 and delivered a reversible capacity of 55.9 mA h g-1 at 250 mA g–1 even after 10000 cycles, being the first to report for sodium cells. The investigation of charge-storage mechanisms [1] showed that the electrochemical performance of V4O9 is surface controlled at very high rate but can still be considered an intercalation material when used at lower or medium rate providing a total high capacity. Of special interest for V4O9 application is that it stands very long cycling making it a challenging/ competitive cathode with high capacity and cyclability to replace expensive electrode compounds

C. M. S. acknowledges funding from the European Union’s Horizon 2020 research and innovation programme under the Marie Skłodowska-Curie Actions (MSCA) grant agreement Number 898264. F.G, AK and E.G thank MCIN/AEI/10.13039/ 501100011033 for funding the projects PID2019-106662RB-C41, C44 and PID2022-139039OB-C21, C22. Financial support from the Universidad San Pablo is also acknowledged. Authors thank Centro Nacional de Microscopía Electronica at Universidad Complutense de Madrid (ICTS ELECMI) for electron microscopy facilities and the SCAI of the University of Málaga for the BET experiments. O.G.P. and E.R.C. acknowledge project TED2021-130756B-C31 MCIN/AEI/10.13039/ 501100011033 and “ERDF A way of making Europe” by the European Union Next Generation EU/PRTR.
