Designing highly lithiophilic interlayers to inhibit lithium dendrite formation in solid-state batteries with garnet-type electrolytes
Sung Ryul Choi a, Seojeong Yoo a, Jun-young Park a
a Sejong University, 209, Neungdong-ro, Gwangjin-gu, Seoul, Korea, Republic of
Proceedings of 24th International Conference on Solid State Ionics (SSI24)
Emerging Materials for High-Performance Devices
London, United Kingdom, 2024 July 14th - 19th
Organizers: John Kilner and Stephen Skinner
Poster, Sung Ryul Choi, 033
Publication date: 10th April 2024

With the widespread use of portable electronic devices and electric vehicles (EVs), the development of next-generation battery systems emphasizing both safety and high energy density has become increasingly crucial. In this context, all-solid-state batteries (ASSBs) featuring inorganic electrolytes have emerged as leading candidates due to their superior safety features, particularly their non-flammable nature. Additionally, the potential for high energy density in ASSBs is attributed to the adoption of a Li-metal anode with a specific capacity of 3860 mAh·g−1 and the lowest redox potential (0 V versus Li/Li+) among lithium-ion batteries [1]. Among inorganic electrolytes, cubic garnet-type Li7La3Zr2O12 (LLZO) electrolytes have garnered significant interest for their high ionic conductivities at room temperature (~1 mS·cm−1) and their thermodynamic stability against Li-metal [2-4]. Despite these advantages, practical application has been hindered by premature short-circuits caused by the penetration of Li dendrites through the rigid LLZO. Studies have shown dendrite penetration even at low current densities of 0.1 to 1.0 mA·cm−2 at room temperature, falling short of meeting fast-charging targets for EVs [5].



Recent research has highlighted that one crucial factor in Li dendrite formation is the interfacial inhomogeneity arising from poor Li wettability between Li metal and the LLZO electrolyte [6]. This inhomogeneous contact can generate uneven electrical distribution sites, leading to extremely high localized current densities [7]. Efforts to improve the lithiophilic properties of LLZO electrolytes have been extensive, aiming to mitigate this inhomogeneity [8-10]. Studies have demonstrated that removing interface impurities effectively enhances lithium wettability [11]. Additionally, the insertion of lithiophilic interlayers, such as metal/metal oxide, at the Li-metal–LLZO interface has shown notable performance improvements [12-14]. However, Li dendrites still occur even at low critical current densities (CCD) below 3.0 mA·cm−2 [15].



Our approach aims to address the inhomogeneity between Li metal and Li6.4La3Zr1.4Ta0.6O12 (LLZTO) electrolyte by utilizing a molten salt technique involving metal chloride. The interlayer, facilitated by the molten salt technique, significantly reduces the interfacial area-specific resistance (ASR) due to the improved wettability of Li metal. Consequently, this results in more uniform Li plating/stripping, achieving a higher CCD at 25°C in a Li/LLZTO/Li symmetric cell. Galvanostatic cycling in the symmetric cell demonstrates exceptional long-term durability.

This work was supported by the Basic Science Research Program’s financial support through the National Research Foundation of Korea (NRF-2020R1A6A1A03043435). It was also supported by the South Korea through the International Cooperative R&D program (P0021202) and the HRD Program for Industrial Innovation (P0023521) of Korea Institute for Advancement of Technology (KIAT) with financial resources granted by the Ministry of Trade, Industry and Energy (MOTIE, Korea).
