Gas diffusion electrodes based on transition metal oxides supported on polybenzoxazine-derived M-N-Cs for the efficient production of syngas
Ignacio Sanjuán Moltó a, Corina Andronescu a, Vimanshu Chanda a, Vaibhav Kumbhar a
a Technical Chemistry III, Faculty of Chemistry, and CENIDE (Center for Nanointegration University Duisburg-Essen), Carl-Benz-Straße, 199, Duisburg, Germany
Materials for Sustainable Development Conference (MATSUS)
Proceedings of Materials for Sustainable Development Conference (MAT-SUS) (NFM22)
#SusEnergy - Sustainable materials for energy storage and conversion
Barcelona, Spain, 2022 October 24th - 28th
Organizers: Tim-Patrick Fellinger and Magda Titirici
Contributed talk, Ignacio Sanjuán Moltó, presentation 136
DOI: https://doi.org/10.29363/nanoge.nfm.2022.136
Publication date: 11th July 2022

The electrochemical reduction of CO2 (eCO2RR) is a promising eco-friendly alternative to fossil-fuel-based processes used for the production of chemicals. Currently, the conversion of CO2 to CO is a more industrially appealing process than the eCO2RR to multicarbon products, as it requires lower energy consumption and presents high product selectivity.[1] Also, the concomitant hydrogen evolution reaction (HER) occurring at the same potential window is not a serious setback in this case since the mixture of H2 and CO (known as syngas) is a valuable product, which can be directly utilized in established industrial processes such as the Fischer-Tropsch to produce energy-dense chemicals. [2] Silver- and gold-based materials are hitherto considered the state-of-the-art of CO-forming catalysts but their cost and scarcity impede their industrial application. In this regard, composite materials based on transition metal oxide nanoparticles supported on metal-nitrogen-doped carbons (MOx/M-N-C) have been recently explored as inexpensive and efficient electrocatalysts for the eCO2RR-to-syngas process. Several works in literature have reported the synergistic effect between MOx nanoparticles and M-N-Cs, which results in an enhanced eCO2RR electrocatalysis with respect to each one of the materials separately. [3,4] The research of MOx/M-N-Cs for eCO2RR is still in its infancy and, therefore, further development is needed to reach the application of these materials in industrial CO2 electrolyzers.

In this contribution, we introduce several approaches for the preparation of effective MOx/M-N-C-based GDEs. On the one hand, we demonstrate the potential of polybenzoxazine (pBO) resins to synthesize active MOx/M-N-Cs materials, most likely due to the unique properties of the resins. In doing so, we report that gas diffusion electrodes (GDEs) prepared with pBO-derived MOx/M-N-Cs (M= Ni, Fe) exhibited higher activity and CO selectivity in 1 M KOH than the pBO-free ones. On the other hand, we explore the optimization of GDEs in terms of eCO2RR electrocatalysis by the addition of binders into the catalyst layer (CL). The addition of PTFE to the catalyst layer was proved to favor the production of CO over HER, disclosing the essential role of hydrophobicity in the CL for eCO2RR. The GDE fabricated with pBO-derived NiOx/Ni-N-C and PTFE displayed suitable syngas production at industrial current densities, with an H2/CO ratio of ~0.9 at -200 mA cm-2 and ~-0.6 V vs RHE. Finally, we also conclude that the combination of PTFE and Sustainion in the CL has a synergistic effect that confers stability to the pBO-derived NiOx/Ni-N-C-based GDE while keeping intact the hydrophobicity, activity, and CO selectivity, with respect to the GDE with only PTFE. The results of this work provide relevant insight into both the development of MOx/M-N-C materials as syngas-forming electrocatalysts and the engineering of eCO2RR-to-CO GDEs aiming for the industrial implementation.

C.A., I.S., V.C., and V.K. acknowledge funding by the BMBF in the framework of the NanomatFutur project “MatGasDif” (03XP0263). V.C. is grateful to IMPRS-SURMAT for a Ph.D. fellowship. Dr. Kateryna Loza and Dr. Ulrich Hagemann (University of Duisburg-Essen) are acknowledged for SEM and XPS measurements, respectively. Prof. Dr. Stephan Schulz and Dr. George Bendt are acknowledged for the powder-XRD analysis. Bright Nsolebna Jaato is acknowledged by the analysis of the XPS spectra.
