The ability to three-dimensionally pattern semiconducting electronic and optoelectronic materials could provide a transformative approach to creating active electronic devices without the need for a cleanroom or conventional microfabrication facility. This could enable the generation of active electronics on-the-fly, using only source inks and a portable 3D printer to enable electronics anywhere, including directly on the body. Indeed, interfacing active devices with biology in 3D could impact a variety of fields, including biomedical devices, regenerative biomedicines, bioelectronics, smart prosthetics, and human-machine interfaces. Indeed, developing the ability to 3D print various classes of materials possessing distinct properties could enable the freeform generation of active electronics in unique functional, interwoven architectures. Achieving seamless integration of diverse materials with 3D printing is a significant challenge which requires overcoming discrepancies in material properties in addition to ensuring that all the materials are compatible with the 3D printing process. We will present a strategy for three-dimensionally integrating diverse classes of materials using a custom-built 3D printer to fully create fully integrated device components with active properties. As a proof of concept for demonstrating the integrated functionality of these materials, we 3D printed quantum dot-based light-emitting diodes (QD-LEDs) that exhibit pure and tunable color emission properties, and polymer-based photodiodes for bionic eye applications, which are conformally printed onto curvilinear surfaces. These results represent a critical initial step toward the large-scale 3D printing of multifunctional materials and devices, without the need for conventional microfabrication processes or facilities.
