Dramatically improving the stability of transparent silver electrodes for high performance organic photovoltaics using a molecular monolayer
Jaemin Lee a, Ross Hatton a
a University of Warwick, Department of Chemistry, Gibbet Hill Road, Coventry, United Kingdom
Proceedings of Interfaces in Organic and Hybrid Thin-Film Optoelectronics (INFORM)
València, Spain, 2019 March 5th - 7th
Organizers: Natalie Stingelin, Hendrik Bolink and Michele Sessolo
Oral, Jaemin Lee, presentation 059
DOI: https://doi.org/10.29363/nanoge.inform.2019.059
Publication date: 8th January 2019

Vacuum evaporation is proven as a low cost method for the large area deposition of metal films and so is widely used in the food packaging industry. At the same time silver (Ag) films with a thickness of 6-10 nm are promising as the basis for flexible transparent electrodes for organic photovoltaics and displays. However, due to the high surface energy of silver and its slow rate of oxidation in air, very thin evaporated Ag films are morphologically unstable even at room temperature. Consequently, for practical application there is a need to identify an easily implementable and versatile means of imparting long term stability. This talk will describe how a single layer of a bifunctional small molecule deposited from the vapor phase can greatly enhance the morphological and chemical stability of optically thin Ag film electrodes. Due to its very low thickness (~1 nm) this organic layer does not electrically isolate the electrode. It is shown that in 10% efficient inverted, top-illuminated and semi-transparent OPVs substantial improvements in device stability are achieved by inclusion of this layer, which is remarkable give its very low thickness.
