Coupling Photovoltaics and Batteries: Direct Solar Energy Storage Concepts and Recent Developments on Solar Battery Devices
Filip Podjaski a, Andreas Gouder b, Julia Kroeger b, Bettina V. Lotsch b
a Department of Chemistry, Imperial College London Molecular Sciences Research Hub, White City Campus 80 Wood Lane, London W12 0BZ, UK
b Max Planck Institute for Solid State Research, Stuttgart, Germany, Germany
International Conference on Hybrid and Organic Photovoltaics
Proceedings of International Conference on Hybrid and Organic Photovoltaics (HOPV23)
London, United Kingdom, 2023 June 12th - 14th
Organizers: Tracey Clarke, James Durrant and Trystan Watson
Poster, Filip Podjaski, 158
Publication date: 30th March 2023

The fluctuating nature of renewable energy sources demands novel concepts bridging energy conversion and storage. The emerging field of solar batteries offers solutions that combine light absorption and electrical energy storage for subsequent use. In this talk, an overview of existing concepts is given, emphasizing on bifunctional materials, which can intrinsically combine light absorption and charge storage. They promise significantly reduced fabrication costs and device complexity of solar energy storage systems.

Operation of bifunctional materials relies on light induced redox-reactions in the photoabsorber material, being commonly assisted by ions from the environment. As such, different types of photo(de-)intercalation concepts can be exploited for bifunctional solar battery photo-anodes and -cathodes.[1] To date, most concepts rely on bifunctional half-cells only, which store counter-charges in an electrolyte. However, technologies more reminiscent of batteries with solid state electrodes are emerging. Of particular interest here is the carbon nitride poly(heptazine imide) or PHI, which can store electrons even in aqueous conditions, at potentials negative of the reversible hydrogen electrode. These properties were previously exploited for solar battery anode half cells,[2] for photocatalyic hydrogen production after irradiation,[3] for light charged microswimmers,[4] and even for photomemristive sensors,[5] that all rely on electron storage in PHI as half-cell only. By engineering a hole transfer cascade with an organic hole transport and separator material, and a hole storage material, the first full solar battery based on purely earth abundant polymeric materials is now reported.[6] While being inspired from organic solar cells, it can be charged purely by light or electrically – and discharged on demand. Different operation modes of such a device are highlighted and compared, which can increase the effective capacity by 243% if discharged under illumination. Finally, design considerations from modelling such devices are discussed, showing requirements and possibilities for optimizing photocharging kinetics or the battery capacity for the desired application scenario.
