TiO2-based thin film photocatalysts for the photoconversion of sugars in H2 and high value-added co-products
Clément Maheu a, Florian Chabanais a, Mohammed Boujtita b, Pierre-Yves Jouan a, Marie-Paule Besland a, Mireille Richard-Plouet a
a Nantes Université, CNRS, Institut des Matériaux de Nantes Jean Rouxel, IMN, F-44000 Nantes, France
b Nantes Université, CNRS, CEISAM, UMR 6230, F-44000 Nantes, France
ECAT
Proceedings of Catalyst Design Strategies for Photo- and Electrochemical Fuel Synthesis (ECAT25)
Madrid, Spain, 2025 February 10th - 11th
Organizers: Marta Liras and Claudio Ampelli
Oral, Clément Maheu, presentation 017
Publication date: 19th December 2024

Photocatalytic water-splitting is a renewable way to store solar energy under chemical energy and, at the same time, produce alternative fuels. The photoconversion of water consists in a reduction half-reaction that produces H2 and an oxidation half-reaction that produces O2. O2 has limited applications (e.g. production of high-purity O2 for medical purposes), so the performance of the overall process depends only on the H2 production part. The amount of H2 produced and the efficiency of the photocatalysts are critical in amortising the environmental and financial costs of the device.

Alternatively, the Marie Skłodowska-Curie OMATSOLFUEL European project explores materials for the photoconversion of industrial effluents rich in sugars (e.g. dairy or brewing effluents). Such an alternative reaction simultaneously produces H2 and high value-added co-products (e.g. arabinose, erythrose, lactobionic acid), distributing the efforts on both half-reactions. Depending on the quantity, the purity and the cost of the molecules, they can be sold to help achieve a solar H2 production cost of 1 $/kg [1].

The challenge is therefore not only to design more efficient materials that reduce protons in H2 and achieve the highest solar to hydrogen value, but also to design materials that are efficient and selective for reduction and oxidation. Proof of concept for photoconversion of sugar-rich reactive mixtures already exists, but more comprehensive studies are needed [2], [3]. Fine structure-activity relationships need to be established between the intrinsic properties of the materials and their photocatalytic activity.

Therefore, we have been working on TiO2-based model photocatalytic systems; thin films prepared by plasma-based techniques (i.e. magnetron sputtering (MS) and plasma-enhanced chemical vapour deposition (PECVD)). These techniques provide access to a wide range of experimental parameters that can be used to tune the structural, electronic and morphological properties of the photocatalysts.

For example, we studied the impact of the TiO2 thickness on its catalytic activity for the photoconversion of glucose. The TOC image shows a clear correlation between this thickness and the photocurrent that has been measured for the photoconversion of a Na2SO4/glucose mixture. This finding is consistent with a previous work about the degradation of methylene blue with TiO2 films prepared by PECVD [4].

We are currently investigating two approaches to boost the photocatalytic performance of the thin films. On the one hand, gold nanoparticles have been deposited by MS. The plasmonic effect is expected to increase visible light absorption and the overall photocatalytic activity. By tuning the power of the plasma or the Ar pressure, we can adjust the density and the morphology of the gold nanoparticles. On the other hand, by using a mixture or Ar/O2/N2 during the MS procedure we were able to prepare TiO2-xNy thin films with different electronic, structural and morphological properties. The experimental parameters were studied in relation to the catalytic activity measured for the photoconversion of sugars.

C. Maheu thanks the Marie Skłodowska-Curie action for the project OMATSOLFUEL (no. 101105640).
